전면 도어 메커니즘

Maserati Levante Modena S Automatic 3.0 BT V6 4WD 430HP

Illustration Number: 09312

부품 찾기

Maserati Levante Modena S Automatic 3.0 BT V6 4WD 430HP - 전면 도어 메커니즘 (09312)

부품 분해도를 보고 원하는 부품을 찾으세요.:
  • 다이어그램을 드래그하여 위치를 변경할 수 있습니다.
  • 다이어그램을 스크롤하거나 핀치하거나 and buttons
  • 부품 다이어그램에서 핫스팟 1을 클릭하여 표에서 부품을 찾을 수 있습니다.
부품 키
IN
재고 있음
AS
곧 도착
TO
주문하기
PE
문의하세요

사진 부품 번호 설명 가격 (개당) 재고
670071211 외부 도어 핸들 문의하기 주문하기
670118929 외부 도어 핸들 문의하기 주문하기
670270095 외부 도어 핸들 문의하기 주문하기
...and 11 more part variants. See table on right for more details.
사진 부품 번호 설명 가격 (개당) 재고
670109525 LH EXTERNAL DOOR HANDLE RETAINING BRACKET £62.65 주문하기
670109516 우측 외부 도어 핸들 고정 브래킷 £71.92 주문하기
670109519 LH EXTERNAL DOOR HANDLE RETAINING BRACKET £84.73 주문하기
...and 1 more part variants. See table on right for more details.
사진 부품 번호 설명 가격 (개당) 재고
670005442 외부 도어 핸들 개스킷 £1.29 주문하기
사진 부품 번호 설명 가격 (개당) 재고
670154292 SCREW £2.84 주문하기
사진 부품 번호 설명 가격 (개당) 재고
670216495 좌측 전면 도어 잠금장치 £366.49 주문하기
670216495 좌측 전면 도어 잠금장치 £366.49 주문하기
670216491 우측 전면 도어 잠금장치 £420.58 주문하기
...and 3 more part variants. See table on right for more details.
사진 부품 번호 설명 가격 (개당) 재고
670035101 타이 로드 £15.51 재고 있음
사진 부품 번호 설명 가격 (개당) 재고
670032745 전면 좌측 윈도우 런 채널 £16.12 주문하기
670032749 전면 우측 창문 런 채널 £16.12 주문하기
사진 부품 번호 설명 가격 (개당) 재고
670176157 좌측 전면 파워 윈도우 £320.65 주문하기
670176157 좌측 전면 파워 윈도우 £320.65 주문하기
670176156 우측 전면 파워 윈도우 £320.65 주문하기
...and 1 more part variants. See table on right for more details.
사진 부품 번호 설명 가격 (개당) 재고
675000573 도어 잠금 스트라이커 £12.93 주문하기
사진 부품 번호 설명 가격 (개당) 재고
675000302 도어 잠금 회전 플러그 트림 £17.94 재고 있음
670119817 도어 잠금 회전 플러그 트림 문의하기 주문하기
675000301 도어 잠금 회전 플러그 트림 £25.13 재고 있음
...and 20 more part variants. See table on right for more details.
사진 부품 번호 설명 가격 (개당) 재고
675000160 왼쪽 상단 힌지 £19.05 주문하기
675000162 우측 상단 힌지 £31.19 재고 있음
사진 부품 번호 설명 가격 (개당) 재고
675000159 좌측 하단 힌지 £19.05 주문하기
675000161 우측 하단 힌지 £19.05 재고 있음
사진 부품 번호 설명 가격 (개당) 재고
670009758 특수 나사 £1.56 주문하기
사진 부품 번호 설명 가격 (개당) 재고
670012585 플러그 문의하기 주문하기
사진 부품 번호 설명 가격 (개당) 재고
670006984 SCREW £1.75 주문하기
사진 부품 번호 설명 가격 (개당) 재고
675000005 SCREWM 8x15 £1.65 재고 있음
사진 부품 번호 설명 가격 (개당) 재고
675000485 SCREWM10 £1.34 주문하기
사진 부품 번호 설명 가격 (개당) 재고
670034687 가스켓 £2.30 주문하기
사진 부품 번호 설명 가격 (개당) 재고
675000485 SCREWM10 £1.34 주문하기
사진 부품 번호 설명 가격 (개당) 재고
670006983 NUT £1.29 주문하기
모두 보기
FRONT DOORS: MECHANISMS of Maserati Maserati Levante Modena S Automatic 3.0 BT V6 4WD 430HP 다이어그램 탭하여 확대
# 부품 세부 정보 가격
(각)		 수량
다이어그램		 에 추가
장바구니
1 670071211
외부 도어 핸들
WARNING: in order to properly choose the spare part for a specific vehicle model, you must perform the configuration procedure once again and enter the "Assembly Number" or "VIN" Assembly Number 6053787 - 6106797; Not available with: EXTERIOR BLACK KIT - MC SPECIFIC, DOOR HANDLES IN BODY COLOR; 		- 2 Enquire
1 670118929
외부 도어 핸들
WARNING: in order to properly choose the spare part for a specific vehicle model, you must perform the configuration procedure once again and enter the "Assembly Number" or "VIN" Assembly Number 6053787 - 6106797; Available with: DOOR HANDLES IN BODY COLOR ; 		- 2 Enquire
1 670270095
외부 도어 핸들
passenger's side; Available with: EXTENDED KEY-LESS ENTRY Not available with: EXTERIOR BLACK KIT - MC SPECIFIC, DOOR HANDLES IN BODY COLOR; 		- 1 Enquire
1 670270095
외부 도어 핸들
driver's side; Not available with: EXTERIOR BLACK KIT - MC SPECIFIC, DOOR HANDLES IN BODY COLOR; 		- 1 Enquire
1 670118929
외부 도어 핸들
driver's side; Bespoke Assembly Number 6106798 - 99999999; Available with: DOOR HANDLES IN BODY COLOR Not available with: EXTERIOR BLACK KIT - MC SPECIFIC; 		- 1 Enquire
1 670118929
외부 도어 핸들
passenger's side; WARNING: in order to properly choose the spare part for a specific vehicle model, you must perform the configuration procedure once again and enter the "Assembly Number" or "VIN" Assembly Number 6109816 - 99999999; Available with: EXTENDED KEY-LESS ENTRY, DOOR HANDLES IN BODY COLOR Not available with: EXTERIOR BLACK KIT - MC SPECIFIC; 		- 1 Enquire
1 670011311
외부 도어 핸들
passenger's side; WARNING: in order to properly choose the spare part for a specific vehicle model, you must perform the configuration procedure once again and enter the "Assembly Number" or "VIN" Assembly Number 6109816 - 99999999; Not available with: EXTERIOR BLACK KIT - MC SPECIFIC, EXTENDED KEY-LESS ENTRY, DOOR HANDLES IN BODY COLOR; 		- 1 Enquire
1 670118930
외부 도어 핸들
passenger's side; WARNING: in order to properly choose the spare part for a specific vehicle model, you must perform the configuration procedure once again and enter the "Assembly Number" or "VIN" Assembly Number 6109816 - 99999999; Available with: DOOR HANDLES IN BODY COLOR Not available with: EXTERIOR BLACK KIT - MC SPECIFIC, EXTENDED KEY-LESS ENTRY; 		- 1 Enquire
1 670071211
외부 도어 핸들
driver's side; WARNING: in order to properly choose the spare part for a specific vehicle model, you must perform the configuration procedure once again and enter the "Assembly Number" or "VIN" Assembly Number 6106798 - 6109889; Not available with: EXTERIOR BLACK KIT - MC SPECIFIC, DOOR HANDLES IN BODY COLOR; 		- 1 Enquire
1 670071211
외부 도어 핸들
passenger's side; WARNING: in order to properly choose the spare part for a specific vehicle model, you must perform the configuration procedure once again and enter the "Assembly Number" or "VIN" Assembly Number 6109816 - 6109889; Available with: EXTENDED KEY-LESS ENTRY Not available with: EXTERIOR BLACK KIT - MC SPECIFIC, DOOR HANDLES IN BODY COLOR; 		- 1 Enquire
1 670071211
외부 도어 핸들
Passenger Side With Button; WARNING: in order to properly choose the spare part for a specific vehicle model, you must perform the configuration procedure once again and enter the "Assembly Number" or "VIN" Assembly Number 6106798 - 6109815; Not available with: EXTERIOR BLACK KIT - MC SPECIFIC, DOOR HANDLES IN BODY COLOR; 		- 1 Enquire
1 670118929
외부 도어 핸들
Passenger Side With Button; WARNING: in order to properly choose the spare part for a specific vehicle model, you must perform the configuration procedure once again and enter the "Assembly Number" or "VIN" Assembly Number 6106798 - 6109815; Available with: DOOR HANDLES IN BODY COLOR Not available with: EXTERIOR BLACK KIT - MC SPECIFIC; 		- 1 Enquire
1 670011311
외부 도어 핸들
Passenger Side Without Button; WARNING: in order to properly choose the spare part for a specific vehicle model, you must perform the configuration procedure once again and enter the "Assembly Number" or "VIN" Assembly Number 6106798 - 6109815; Not available with: EXTERIOR BLACK KIT - MC SPECIFIC, EXTENDED KEY-LESS ENTRY, DOOR HANDLES IN BODY COLOR; 		- 1 Enquire
1 670118930
외부 도어 핸들
Passenger Side Without Button; WARNING: in order to properly choose the spare part for a specific vehicle model, you must perform the configuration procedure once again and enter the "Assembly Number" or "VIN" Assembly Number 6106798 - 6109815; Available with: DOOR HANDLES IN BODY COLOR Not available with: EXTERIOR BLACK KIT - MC SPECIFIC, EXTENDED KEY-LESS ENTRY; 		- 1 Enquire
2 670109525
LH EXTERNAL DOOR HANDLE RETAINING BRACKET
Bespoke Assembly Number 6069380 - 99999999; EU CN US CD JP ME KO; 		£62.65 (3.8% off) 1
2 670109516
우측 외부 도어 핸들 고정 브래킷
Bespoke Assembly Number 6071254 - 99999999; EU CN US CD JP ME KO; 		£71.92 (3.7% off) 1
2 670109519
LH EXTERNAL DOOR HANDLE RETAINING BRACKET
Bespoke Assembly Number 6071253 - 99999999; AU UK JRH IN SA; 		£84.73 (3.7% off) 1
2 670109524
우측 외부 도어 핸들 고정 브래킷
Bespoke Assembly Number 6069380 - 99999999; AU UK JRH IN SA; 		£60.91 (3.8% off) 1
3 670005442
외부 도어 핸들 개스킷 		£1.29 (4.4% off) 2
4 670154292
SCREW 		£2.84 (5.3% off) 6
5 670216495
좌측 전면 도어 잠금장치
Bespoke Assembly Number 6035538 - 6106279; Available with: SOFT DOOR CLOSE - CENTRALIZED AUTOMATED ELECTRICAL DOORS LOCKING ; EU CN US CD JP ME KO; 		£366.49 (3.8% off) 1
5 670216495
좌측 전면 도어 잠금장치
Bespoke Assembly Number 6035538 - 99999999; Available with: SOFT DOOR CLOSE - CENTRALIZED AUTOMATED ELECTRICAL DOORS LOCKING ; EU CN US CD JP ME KO; 		£366.49 (3.8% off) 1
5 670216491
우측 전면 도어 잠금장치
Bespoke Assembly Number 6082277 - 6104790; Available with: SOFT DOOR CLOSE - CENTRALIZED AUTOMATED ELECTRICAL DOORS LOCKING ; EU CN US CD JP ME KO; 		£420.58 (3.8% off) 1
5 670216491
우측 전면 도어 잠금장치
Bespoke Assembly Number 6082277 - 99999999; Available with: SOFT DOOR CLOSE - CENTRALIZED AUTOMATED ELECTRICAL DOORS LOCKING ; EU CN US CD JP ME KO; 		£420.58 (3.8% off) 1
5 670216496
좌측 전면 도어 잠금장치
Bespoke Assembly Number 6035538 - 99999999; Available with: SOFT DOOR CLOSE - CENTRALIZED AUTOMATED ELECTRICAL DOORS LOCKING ; AU UK JRH IN SA; 		£310.26 1
5 670216492
우측 전면 도어 잠금장치
Bespoke Assembly Number 6035538 - 99999999; Available with: SOFT DOOR CLOSE - CENTRALIZED AUTOMATED ELECTRICAL DOORS LOCKING ; AU UK JRH IN SA;
재고 있음 		£335.22 1
6 670035101
타이 로드
재고 있음 		£15.51 (9.8% off) 1
7 670032745
전면 좌측 윈도우 런 채널 		£16.12 (4% off) 1
7 670032749
전면 우측 창문 런 채널 		£16.12 (4% off) 1
8 670176157
좌측 전면 파워 윈도우
Bespoke Assembly Number 6044652 - 6102427; 		£320.65 (12.2% off) 1
8 670176157
좌측 전면 파워 윈도우
Bespoke Assembly Number 6044652 - 99999999; 		£320.65 (12.2% off) 1
8 670176156
우측 전면 파워 윈도우
Bespoke Assembly Number 6044652 - 6102427; 		£320.65 (12.2% off) 1
8 670176156
우측 전면 파워 윈도우
Bespoke Assembly Number 6102428 - 99999999; 		£320.65 (12.2% off) 1
9 675000573
도어 잠금 스트라이커 		£12.93 (4.2% off) 2
10 675000302
도어 잠금 회전 플러그 트림
LH side; Not available with: EXTERIOR BLACK KIT - MC SPECIFIC, BLACK DOOR HANDLES, DOOR HANDLES IN BODY COLOR; EU CN US CD JP ME KO;
재고 있음 		£17.94 (2% off) 1
10 670119817
도어 잠금 회전 플러그 트림
LH side; WARNING: in order to properly choose the spare part for a specific vehicle model, you must perform the configuration procedure once again and enter the "Assembly Number" or "VIN" Assembly Number 6053787 - 99999999; Available with: DOOR HANDLES IN BODY COLOR Not available with: BLACK DOOR HANDLES; EU CN US CD JP ME KO; 		- 1 Enquire
10 675000301
도어 잠금 회전 플러그 트림
RH side; WARNING: in order to properly choose the spare part for a specific vehicle model, you must perform the configuration procedure once again and enter the "Assembly Number" or "VIN" Assembly Number 0 - 6106797; Not available with: EXTERIOR BLACK KIT - MC SPECIFIC, BLACK DOOR HANDLES, DOOR HANDLES IN BODY COLOR; EU CN US CD JP ME KO;
재고 있음 		£25.13 (1.8% off) 1
10 670119818
도어 잠금 회전 플러그 트림
RH side; WARNING: in order to properly choose the spare part for a specific vehicle model, you must perform the configuration procedure once again and enter the "Assembly Number" or "VIN" Assembly Number 6053787 - 6106797; Available with: DOOR HANDLES IN BODY COLOR Not available with: BLACK DOOR HANDLES; EU CN US CD JP ME KO; 		- 1 Enquire
10 675000302
도어 잠금 회전 플러그 트림
RH side; Not available with: EXTERIOR BLACK KIT - MC SPECIFIC, BLACK DOOR HANDLES, DOOR HANDLES IN BODY COLOR; AU UK JRH IN SA;
재고 있음 		£17.94 (2% off) 1
10 670119817
도어 잠금 회전 플러그 트림
RH side; WARNING: in order to properly choose the spare part for a specific vehicle model, you must perform the configuration procedure once again and enter the "Assembly Number" or "VIN" Assembly Number 6053787 - 99999999; Available with: DOOR HANDLES IN BODY COLOR Not available with: BLACK DOOR HANDLES; AU UK JRH IN SA; 		- 1 Enquire
10 675000300
도어 잠금 회전 플러그 트림
LH Side; WARNING: in order to properly choose the spare part for a specific vehicle model, you must perform the configuration procedure once again and enter the "Assembly Number" or "VIN" Assembly Number 6109816 - 99999999; Not available with: EXTERIOR BLACK KIT - MC SPECIFIC, EXTENDED KEY-LESS ENTRY, DOOR HANDLES IN BODY COLOR; AU UK JRH IN SA; 		£25.47 (5% off) 1
10 670119818
도어 잠금 회전 플러그 트림
LH Side; WARNING: in order to properly choose the spare part for a specific vehicle model, you must perform the configuration procedure once again and enter the "Assembly Number" or "VIN" Assembly Number 6109816 - 99999999; Available with: EXTENDED KEY-LESS ENTRY, DOOR HANDLES IN BODY COLOR Not available with: EXTERIOR BLACK KIT - MC SPECIFIC; AU UK JRH IN SA; 		- 1 Enquire
10 670119819
도어 잠금 회전 플러그 트림
LH Side; WARNING: in order to properly choose the spare part for a specific vehicle model, you must perform the configuration procedure once again and enter the "Assembly Number" or "VIN" Assembly Number 6109816 - 99999999; Available with: DOOR HANDLES IN BODY COLOR Not available with: EXTERIOR BLACK KIT - MC SPECIFIC, EXTENDED KEY-LESS ENTRY; AU UK JRH IN SA; 		- 1 Enquire
10 675000301
도어 잠금 회전 플러그 트림
LH side; Bespoke Assembly Number 6109816 - 99999999; Available with: EXTENDED KEY-LESS ENTRY Not available with: EXTERIOR BLACK KIT - MC SPECIFIC, DOOR HANDLES IN BODY COLOR; AU UK JRH IN SA;
재고 있음 		£25.13 (1.8% off) 1
10 675000300
도어 잠금 회전 플러그 트림
RH Side; WARNING: in order to properly choose the spare part for a specific vehicle model, you must perform the configuration procedure once again and enter the "Assembly Number" or "VIN" Assembly Number 6109816 - 99999999; Not available with: EXTERIOR BLACK KIT - MC SPECIFIC, EXTENDED KEY-LESS ENTRY, DOOR HANDLES IN BODY COLOR; EU CN US CD JP ME KO; 		£25.47 (5% off) 1
10 675000301
도어 잠금 회전 플러그 트림
RH Side; WARNING: in order to properly choose the spare part for a specific vehicle model, you must perform the configuration procedure once again and enter the "Assembly Number" or "VIN" Assembly Number 6109816 - 99999999; Available with: EXTENDED KEY-LESS ENTRY Not available with: EXTERIOR BLACK KIT - MC SPECIFIC, DOOR HANDLES IN BODY COLOR; EU CN US CD JP ME JRH KO;
재고 있음 		£25.13 (1.8% off) 1
10 670119818
도어 잠금 회전 플러그 트림
RH Side; WARNING: in order to properly choose the spare part for a specific vehicle model, you must perform the configuration procedure once again and enter the "Assembly Number" or "VIN" Assembly Number 6109816 - 99999999; Available with: EXTENDED KEY-LESS ENTRY, DOOR HANDLES IN BODY COLOR Not available with: EXTERIOR BLACK KIT - MC SPECIFIC; EU CN US CD JP ME KO; 		- 1 Enquire
10 670119819
도어 잠금 회전 플러그 트림
RH Side; WARNING: in order to properly choose the spare part for a specific vehicle model, you must perform the configuration procedure once again and enter the "Assembly Number" or "VIN" Assembly Number 6109816 - 99999999; Available with: DOOR HANDLES IN BODY COLOR Not available with: EXTERIOR BLACK KIT - MC SPECIFIC, EXTENDED KEY-LESS ENTRY; EU CN US CD JP ME KO; 		- 1 Enquire
10 675000301
도어 잠금 회전 플러그 트림
LH side; WARNING: in order to properly choose the spare part for a specific vehicle model, you must perform the configuration procedure once again and enter the "Assembly Number" or "VIN" Assembly Number 0 - 6106797; Not available with: EXTERIOR BLACK KIT - MC SPECIFIC, BLACK DOOR HANDLES, DOOR HANDLES IN BODY COLOR; AU UK JRH IN SA;
재고 있음 		£25.13 (1.8% off) 1
10 670119818
도어 잠금 회전 플러그 트림
LH side; WARNING: in order to properly choose the spare part for a specific vehicle model, you must perform the configuration procedure once again and enter the "Assembly Number" or "VIN" Assembly Number 6053787 - 6106797; Available with: DOOR HANDLES IN BODY COLOR Not available with: BLACK DOOR HANDLES; AU UK JRH IN SA; 		- 1 Enquire
10 675000301
도어 잠금 회전 플러그 트림
Left side - Handle with button; WARNING: in order to properly choose the spare part for a specific vehicle model, you must perform the configuration procedure once again and enter the "Assembly Number" or "VIN" Assembly Number 6106798 - 6109815; Not available with: EXTERIOR BLACK KIT - MC SPECIFIC, DOOR HANDLES IN BODY COLOR; AU UK JRH IN SA;
재고 있음 		£25.13 (1.8% off) 1
10 670119818
도어 잠금 회전 플러그 트림
Left side - Handle with button; WARNING: in order to properly choose the spare part for a specific vehicle model, you must perform the configuration procedure once again and enter the "Assembly Number" or "VIN" Assembly Number 6106798 - 6109815; Available with: DOOR HANDLES IN BODY COLOR Not available with: EXTERIOR BLACK KIT - MC SPECIFIC; AU UK JRH IN SA; 		- 1 Enquire
10 675000300
도어 잠금 회전 플러그 트림
Left side - Handle without button; WARNING: in order to properly choose the spare part for a specific vehicle model, you must perform the configuration procedure once again and enter the "Assembly Number" or "VIN" Assembly Number 6106798 - 6109815; Not available with: EXTERIOR BLACK KIT - MC SPECIFIC, EXTENDED KEY-LESS ENTRY, DOOR HANDLES IN BODY COLOR; AU UK JRH IN SA; 		£25.47 (5% off) 1
10 670119819
도어 잠금 회전 플러그 트림
Left side - Handle without button; WARNING: in order to properly choose the spare part for a specific vehicle model, you must perform the configuration procedure once again and enter the "Assembly Number" or "VIN" Assembly Number 6106798 - 6109815; Available with: DOOR HANDLES IN BODY COLOR Not available with: EXTERIOR BLACK KIT - MC SPECIFIC, EXTENDED KEY-LESS ENTRY; AU UK JRH IN SA; 		- 1 Enquire
10 675000301
도어 잠금 회전 플러그 트림
Right side - Handle with button; Bespoke Assembly Number 6106798 - 6109815; Not available with: EXTERIOR BLACK KIT - MC SPECIFIC, DOOR HANDLES IN BODY COLOR; EU CN US CD JP ME KO;
재고 있음 		£25.13 (1.8% off) 1
10 675000300
도어 잠금 회전 플러그 트림
Right side - Handle without button; WARNING: in order to properly choose the spare part for a specific vehicle model, you must perform the configuration procedure once again and enter the "Assembly Number" or "VIN" Assembly Number 6106798 - 6109815; Not available with: EXTERIOR BLACK KIT - MC SPECIFIC, EXTENDED KEY-LESS ENTRY, DOOR HANDLES IN BODY COLOR; EU CN US CD JP ME KO; 		£25.47 (5% off) 1
10 670119819
도어 잠금 회전 플러그 트림
Right side - Handle without button; WARNING: in order to properly choose the spare part for a specific vehicle model, you must perform the configuration procedure once again and enter the "Assembly Number" or "VIN" Assembly Number 6106798 - 6109815; Available with: DOOR HANDLES IN BODY COLOR Not available with: EXTERIOR BLACK KIT - MC SPECIFIC, EXTENDED KEY-LESS ENTRY; EU CN US CD JP ME KO; 		- 1 Enquire
11 675000160
왼쪽 상단 힌지 		£19.05 (3.8% off) 1
11 675000162
우측 상단 힌지
재고 있음 		£31.19 (3.7% off) 1
12 675000159
좌측 하단 힌지 		£19.05 (3.8% off) 1
12 675000161
우측 하단 힌지
재고 있음 		£19.05 (3.8% off) 1
13 670009758
특수 나사 		£1.56 (5.5% off) 2
14 670012585
플러그 		- 1 Enquire
15 670006984
SCREW 		£1.75 (5.4% off) 2
16 675000005
SCREWM 8x15
재고 있음 		£1.65 (5.7% off) 4
17 675000485
SCREWM10 		£1.34 (4.3% off) 4
18 670034687
가스켓 		£2.30 (4.2% off) 2
19 675000485
SCREWM10 		£1.34 (4.3% off) 4
20 670006983
NUT 		£1.29 (4.4% off) 4
