Ferrari Purosangue USA - 뒷좌석

부품 분해도를 보고 원하는 부품을 찾으세요.:
  • 다이어그램을 드래그하여 위치를 변경할 수 있습니다.
  • 다이어그램을 스크롤하거나 핀치하거나 and buttons
  • 부품 다이어그램에서 핫스팟 1을 클릭하여 표에서 부품을 찾을 수 있습니다.
부품 키
IN
재고 있음
AS
곧 도착
TO
주문하기
PE
문의하세요

사진 부품 번호 설명 가격 (개당) 재고
775447 LH REAR SEAT 문의하기 주문하기
775467 LH REAR SEAT 문의하기 주문하기
775448 LH REAR SEAT $32,578.82 주문하기
...and 41 more part variants. See table on right for more details.
사진 부품 번호 설명 가격 (개당) 재고
864047 SCREW $2.70 주문하기
사진 부품 번호 설명 가격 (개당) 재고
886694 SCREW $2.59 주문하기
사진 부품 번호 설명 가격 (개당) 재고
774936 LH 뒷좌석 배선 하네스 문의하기 주문하기
774973 LH 뒷좌석 배선 하네스 문의하기 주문하기
774974 RH 뒷좌석 와이어링 하네스 문의하기 주문하기
...and 1 more part variants. See table on right for more details.
사진 부품 번호 설명 가격 (개당) 재고
971046 LH 4W 시트 컨트롤 $1,314.22 주문하기
805489 RH 4W 시트 컨트롤 $1,314.22 주문하기
사진 부품 번호 설명 가격 (개당) 재고
55011160 NAG/NAP ECU $1,250.88 주문하기
55011162 NAG/NAP ECU $1,250.88 주문하기
사진 부품 번호 설명 가격 (개당) 재고
831729 버클 섹션 $128.24 주문하기
모두 보기
REAR SEATS of Ferrari Ferrari Purosangue USA 다이어그램 탭하여 확대
# 부품 세부 정보 가격
(각)		 수량
다이어그램		 에 추가
장바구니
0001 775447
LH REAR SEAT
Standard - Base - Size Large - INTP - DAAL - STC1 - STC2 - 1CAV - EMPH - 1BAC - Select 1BAC for leather upholstery in colour of customer's choice - See detail A in attached image 		- 1 Enquire
0001 775467
LH REAR SEAT
Standard - Base - Size Large - INTP - DAAL - STC1 - STC2 - 1CAV - EMPH - 1BAC - Select 1BAC for leather upholstery in colour of customer's choice - See detail A in attached image 		- 1 Enquire
0001 775448
LH REAR SEAT
Standard - Ventilated and heated - Size Large - INTP - DAAL - STC1 - STC2 - 1CAV - EMPH - 1BAC - Select 1BAC for leather upholstery in colour of customer's choice - See detail B in attached image 		$32,578.82 1
0001 775510
LH REAR SEAT
Standard - Ventilated and heated - Size Large - INTP - DAAL - STC1 - STC2 - 1CAV - EMPH - 1BAC - Select 1BAC for leather upholstery in colour of customer's choice - See detail B in attached image 		- 1 Enquire
0001 775438
LH REAR SEAT
Style - Leather - Size Large - INTP - STC1 - STC2 - 1CAV - EMPH - PIP1 - 1BAC - Select 1BAC for leather upholstery in colour of customer's choice - See detail C in attached image 		- 1 Enquire
0001 775547
LH REAR SEAT
Style - Leather - Size Large - INTP - STC1 - STC2 - 1CAV - EMPH - PIP1 - 1BAC - Select 1BAC for leather upholstery in colour of customer's choice - See detail C in attached image 		- 1 Enquire
0001 775426
LH REAR SEAT
Style - Ventilated and heated - Leather - Size Large - INTP - STC1 - STC2 - 1CAV - EMPH - PIP1 - CLDT - 1BAC - Select 1BAC for leather upholstery in colour of customer's choice - See detail D in attached image 		$37,363.91 1
0001 775456
LH REAR SEAT
Style - Ventilated and heated - Leather - Size Large - INTP - STC1 - STC2 - 1CAV - EMPH - PIP1 - CLDT - 1BAC - Select 1BAC for leather upholstery in colour of customer's choice - See detail D in attached image 		- 1 Enquire
0001 775439
LH REAR SEAT
Semi-aniline leather - Standard - Ventilated and heated - Size Large - STC1 - STC2 - 1CAV - EMPH - Seat in Fondente semi-aniline leather - See detail E in attached image 		- 1 Enquire
0001 775457
LH REAR SEAT
Semi-aniline leather - Standard - Ventilated and heated - Size Large - STC1 - STC2 - 1CAV - EMPH - Seat in Fondente semi-aniline leather - See detail E in attached image 		- 1 Enquire
0001 775429
LH REAR SEAT
Semi-aniline leather - Style - Ventilated and heated - Size Large - STC1 - STC2 - 1CAV - EMPH - PIP1 - CLDT - Seat in Fondente semi-aniline leather - See detail F in attached image 		- 1 Enquire
0001 775459
LH REAR SEAT
Semi-aniline leather - Style - Ventilated and heated - Size Large - STC1 - STC2 - 1CAV - EMPH - PIP1 - CLDT - Seat in Fondente semi-aniline leather - See detail F in attached image 		- 1 Enquire
0001 775428
LH REAR SEAT
Semi-aniline leather - Goldrake - Ventilated and heated - Size Large - STC1 - STC2 - 1CAV - EMPH - PIP1 - CLDT - Seat in Fondente semi-aniline leather - See detail G in attached image 		- 1 Enquire
0001 775465
LH REAR SEAT
Semi-aniline leather - Goldrake - Ventilated and heated - Size Large - STC1 - STC2 - 1CAV - EMPH - PIP1 - CLDT - Seat in Fondente semi-aniline leather - See detail G in attached image 		$32,578.82 1
0001 775435
LH REAR SEAT
Goldrake - Base - Size Large - INTP - DAAL - STC1 - STC2 - 1CAV - EMPH - 1BAC - Select 1BAC for leather upholstery in colour of customer's choice - See detail H in attached image 		- 1 Enquire
0001 775534
LH REAR SEAT
Goldrake - Base - Size Large - INTP - DAAL - STC1 - STC2 - 1CAV - EMPH - 1BAC - Select 1BAC for leather upholstery in colour of customer's choice - See detail H in attached image 		- 1 Enquire
0001 775434
LH REAR SEAT
Goldrake - Ventilated and heated - Size Large - INTP - DAAL - STC1 - STC2 - 1CAV - EMPH - CLDT - 1BAC - Select 1BAC for leather upholstery in colour of customer's choice - See detail I in attached image 		- 1 Enquire
0001 775473
LH REAR SEAT
Goldrake - Ventilated and heated - Size Large - INTP - DAAL - STC1 - STC2 - 1CAV - EMPH - CLDT - 1BAC - Select 1BAC for leather upholstery in colour of customer's choice - See detail I in attached image 		- 1 Enquire
0001 775437
LH REAR SEAT
Goldrake - Base - Leather - Size Large - INTP - STC1 - STC2 - 1CAV - EMPH - PIP1 - 1BAC - Select 1BAC for leather upholstery in colour of customer's choice - See detail L in attached image 		- 1 Enquire
0001 775551
LH REAR SEAT
Goldrake - Base - Leather - Size Large - INTP - STC1 - STC2 - 1CAV - EMPH - PIP1 - 1BAC - Select 1BAC for leather upholstery in colour of customer's choice - See detail L in attached image 		- 1 Enquire
0001 775423
LH REAR SEAT
Goldrake - Ventilated and heated - Leather - Size Large - INTP - STC1 - STC2 - 1CAV - EMPH - PIP1 - CLDT - 1BAC - Select 1BAC for leather upholstery in colour of customer's choice - See detail M in attached image 		$32,578.82 1
0001 775511
LH REAR SEAT
Goldrake - Ventilated and heated - Leather - Size Large - INTP - STC1 - STC2 - 1CAV - EMPH - PIP1 - CLDT - 1BAC - Select 1BAC for leather upholstery in colour of customer's choice - See detail M in attached image 		- 1 Enquire
0001 775445
RH REAR SEAT
Standard - Base - Size Large - INTP - DAAL - STC1 - STC2 - 1CAV - EMPH - 1BAC - Select 1BAC for leather upholstery in colour of customer's choice - See detail A in attached image 		- 1 Enquire
0001 775468
RH REAR SEAT
Standard - Base - Size Large - INTP - DAAL - STC1 - STC2 - 1CAV - EMPH - 1BAC - Select 1BAC for leather upholstery in colour of customer's choice - See detail A in attached image 		- 1 Enquire
0001 775446
RH REAR SEAT
Standard - Ventilated and heated - Size Large - INTP - DAAL - STC1 - STC2 - 1CAV - EMPH - 1BAC - Select 1BAC for leather upholstery in colour of customer's choice - See detail B in attached image 		$32,578.82 1
0001 775462
RH REAR SEAT
Standard - Ventilated and heated - Size Large - INTP - DAAL - STC1 - STC2 - 1CAV - EMPH - 1BAC - Select 1BAC for leather upholstery in colour of customer's choice - See detail B in attached image 		- 1 Enquire
0001 775433
RH REAR SEAT
Style - Leather - Size Large - INTP - STC1 - STC2 - 1CAV - EMPH - PIP1 - 1BAC - Select 1BAC for leather upholstery in colour of customer's choice - See detail C in attached image 		- 1 Enquire
0001 775499
RH REAR SEAT
Style - Leather - Size Large - INTP - STC1 - STC2 - 1CAV - EMPH - PIP1 - 1BAC - Select 1BAC for leather upholstery in colour of customer's choice - See detail C in attached image 		- 1 Enquire
0001 775422
RH REAR SEAT
Style - Ventilated and heated - Leather - Size Large - INTP - STC1 - STC2 - 1CAV - EMPH - PIP1 - CLDT - 1BAC - Select 1BAC for leather upholstery in colour of customer's choice - See detail D in attached image 		$37,363.91 1
0001 775461
RH REAR SEAT
Style - Ventilated and heated - Leather - Size Large - INTP - STC1 - STC2 - 1CAV - EMPH - PIP1 - CLDT - 1BAC - Select 1BAC for leather upholstery in colour of customer's choice - See detail D in attached image 		- 1 Enquire
0001 775440
RH REAR SEAT
Semi-aniline leather - Standard - Ventilated and heated - Size Large - STC1 - STC2 - 1CAV - EMPH - Seat in Fondente semi-aniline leather - See detail E in attached image 		- 1 Enquire
0001 775466
RH REAR SEAT
Semi-aniline leather - Standard - Ventilated and heated - Size Large - STC1 - STC2 - 1CAV - EMPH - Seat in Fondente semi-aniline leather - See detail E in attached image 		- 1 Enquire
0001 775427
RH REAR SEAT
Semi-aniline leather - Style - Ventilated and heated - Size Large - STC1 - STC2 - 1CAV - EMPH - PIP1 - CLDT - Seat in Fondente semi-aniline leather - See detail F in attached image 		- 1 Enquire
0001 775549
RH REAR SEAT
Semi-aniline leather - Style - Ventilated and heated - Size Large - STC1 - STC2 - 1CAV - EMPH - PIP1 - CLDT - Seat in Fondente semi-aniline leather - See detail F in attached image 		- 1 Enquire
0001 775425
RH REAR SEAT
Semi-aniline leather - Goldrake - Ventilated and heated - Size Large - STC1 - STC2 - 1CAV - EMPH - PIP1 - CLDT - Seat in Fondente semi-aniline leather - See detail G in attached image 		- 1 Enquire
0001 775464
RH REAR SEAT
Semi-aniline leather - Goldrake - Ventilated and heated - Size Large - STC1 - STC2 - 1CAV - EMPH - PIP1 - CLDT - Seat in Fondente semi-aniline leather - See detail G in attached image 		$38,766.82 1
0001 775431
RH REAR SEAT
Goldrake - Base - Size Large - INTP - DAAL - STC1 - STC2 - 1CAV - EMPH - 1BAC - Select 1BAC for leather upholstery in colour of customer's choice - See detail H in attached image 		- 1 Enquire
0001 775482
RH REAR SEAT
Goldrake - Base - Size Large - INTP - DAAL - STC1 - STC2 - 1CAV - EMPH - 1BAC - Select 1BAC for leather upholstery in colour of customer's choice - See detail H in attached image 		- 1 Enquire
0001 775430
RH REAR SEAT
Goldrake - Ventilated and heated - Size Large - INTP - DAAL - STC1 - STC2 - 1CAV - EMPH - CLDT - 1BAC - Select 1BAC for leather upholstery in colour of customer's choice - See detail I in attached image 		- 1 Enquire
0001 775550
RH REAR SEAT
Goldrake - Ventilated and heated - Size Large - INTP - DAAL - STC1 - STC2 - 1CAV - EMPH - CLDT - 1BAC - Select 1BAC for leather upholstery in colour of customer's choice - See detail I in attached image 		- 1 Enquire
0001 775432
RH REAR SEAT
Goldrake - Base - Leather - Size Large - INTP - STC1 - STC2 - 1CAV - EMPH - PIP1 - 1BAC - Select 1BAC for leather upholstery in colour of customer's choice - See detail L in attached image 		- 1 Enquire
0001 775484
RH REAR SEAT
Goldrake - Base - Leather - Size Large - INTP - STC1 - STC2 - 1CAV - EMPH - PIP1 - 1BAC - Select 1BAC for leather upholstery in colour of customer's choice - See detail L in attached image 		- 1 Enquire
0001 775424
RH REAR SEAT
Goldrake - Ventilated and heated - Leather - Size Large - INTP - STC1 - STC2 - 1CAV - EMPH - PIP1 - CLDT - 1BAC - Select 1BAC for leather upholstery in colour of customer's choice - See detail M in attached image 		$32,578.82 1
0001 775463
RH REAR SEAT
Goldrake - Ventilated and heated - Leather - Size Large - INTP - STC1 - STC2 - 1CAV - EMPH - PIP1 - CLDT - 1BAC - Select 1BAC for leather upholstery in colour of customer's choice - See detail M in attached image 		- 1 Enquire
0002 864047
SCREW
M10 X 1.25 X 25 		$2.70 4
0003 886694
SCREW
M10 X 1.25 X 25 		$2.59 4
0004 774936
LH 뒷좌석 배선 하네스
Applicable for base version 		- 1 Enquire
0004 774973
LH 뒷좌석 배선 하네스
Applicable for ventilated, heated version 		- 1 Enquire
0004 774974
RH 뒷좌석 와이어링 하네스
Applicable for base version 		- 1 Enquire
0004 774988
RH 뒷좌석 와이어링 하네스
Applicable for ventilated, heated version 		- 1 Enquire
0005 971046
LH 4W 시트 컨트롤 		$1,314.22 1
0005 805489
RH 4W 시트 컨트롤 		$1,314.22 1
0006 55011160
NAG/NAP ECU
Applicable for base version 		$1,250.88 2
0006 55011162
NAG/NAP ECU
Applicable for ventilated, heated version 		$1,250.88 2
0008 831729
버클 섹션 		$128.24 2
